Product Details:
|
| Minimum Order Quantity: | 30 KM | Packaging Details: | 100M Roll, 300M / 500M Wooden Spool, Carton |
|---|---|---|---|
| Delivery Time: | Normally 15 Days | Payment Terms: | T/T, L/C |
| Supply Ability: | 50*20’GP / Month | Conductor: | Bare Copper |
| Insulation: | Mylar PVC | Drain Wire: | Yes |
| Rip Cord: | Yes | Jacket: | Mylar PVC |
| Color: | Gray | Package: | 100M Roll, 300M / 500M Wooden Spool, Carton |
| High Light: | shielded Alarm Cable,screened alarm cable |
||
Quick Detail:
Description:
Myalar Screened Cable use conductor of Stranded or Solid CU/CCA/TCCA conductor,mainly in 100M
Applications:
Wiring Burglar & Security alarms, public address systems,intercoms,telephone stations, speakers,instrumentation,control and other low voltage circuits that are power limited.
|
KT1311 Mylar Screened Cable 1 Pair 0.40mm2 0.50mm2 1.00mm2 Stranded Conductor Gray |
||
| 0.40mm2 Construction | ||
| Conductor | 12 x 0.20mm | CU/CCA/TCCA |
| Pairs | 1 | |
| Insulation | 1.50mm PVC | |
| Drain Wire | 12 x 0.20mm | CU/CCA/TCCA |
| Outer jacket | Overall Diameter (mm) | 4.8 ± 0.1 mm |
| Thickness (mm) | 0.80 mm | |
| Raw Material | PVC(RoHs) flame retardant | |
| Marking | KINGTONE Mylar Screened Cable 1 Pair 0.40mm2 Stranded Gray | |
| 0.50mm2 Construction | ||
| Conductor | 16 x 0.20mm | CU/CCA/TCCA |
| Pairs | 1 | |
| Insulation | 1.65mm PVC | |
| Drain Wire | 16 x 0.20mm | CU/CCA/TCCA |
| Outer jacket | Overall Diameter (mm) | 5.5 ± 0.1 mm |
| Thickness (mm) | 0.80 mm | |
| Raw Material | PVC(RoHs) flame retardant | |
| Marking | KINGTONE Mylar Screened Cable 1 Pair 0.50mm2 Stranded Gray | |
| 1.00mm2 Construction | ||
| Conductor | 32 x 0.20mm | CU/CCA/TCCA |
| Pairs | 1 | |
| Insulation | 2.20mm PVC | |
| Drain Wire | 32 x 0.20mm | CU/CCA/TCCA |
| Rip Cord | Cotton Wire | |
| Outer jacket | Overall Diameter (mm) | 6.2 ± 0.1 mm |
| Thickness (mm) | 0.80 mm | |
| Raw Material | PVC(RoHs) flame retardant | |
| Marking | KINGTONE Mylar Screened Cable 1 Pair 1.00mm2 Stranded Gray | |
| Order Informations: | ||
| Inner Package | 100m/Roll, 500m/Spool (or Per customer's request) | |
| Outer Package | Carton, Color Box, Pallet (or Per customer's request) | |
| Delivery time | Normally 15 days after received the deposit. | |
